Instance 2 Attributes: Polled I/O
Attribute Access
1 Get
2 Get
3 Get
4 Get
5 Get
6 Get
7 Get
8 Get
9 Get/Set
12 Get
13 Get
14 Get
15 Get
16 Get
17 Get
MG.90.B2.02 - VLT is a registered Danfoss trade mark
Name Datatype
State USINT
Instance Type USINT
Transport Class Trigger USINT
Produced Connection ID UINT
Consumed Connection ID UINT
Initial Communication USINT
Characteristics
Produced Connection size UINT
Consumed Connection size UINT
Expected Package UINT
Watchdog timeout action USINT
Produced Connection Path UINT
Length
Produced Connection Path Array of USINT
Consumed Connection Path UINT
Length
Consumed Connection Path Array of USINT
Production Inhibit Time UINT
®
VLT 2800 / FCD 300 DeviceNet
State of the object
Indicates either I/O or Messages Connection
Defines behaviour of the Connection
CAN Identifier Field when the Connection transmits
AN Identifier Field value that denotes message to
be received
Defines the message group(s) across which
productions and consumptions associated with this
Connection occur
Maximum number of bytes transmitted across this
Connection
Maximum number of bytes received across this
Connection
Defines timming associated with this Connection
Defines how to handle Inactivity/Watchdog timeout
Number of Bytes in the produced connection path
attribute
Specifies the Application Object(s) whose data is to
be produced by these Connection Objects
Number of bytes in the consumed connection path
attribute
Specifies the Application object(s) that are to receive
the data consumed by this Connection object
Defines minimum time between new data production.
This attribute is required for I/O Client connection
Description
