I

EDS Files

Note that the EDS files can be uploaded from the
VLT frequency converters via RS Networx. Before
uploading the EDS file you must check the version
of RS Networx in Help and About RS Networx. RS
Networx version 3.11.00 supports the format Errata 2
and no changes must be made to the VLT frequency
converter. RS Networx version 3.00.00 supports
Errata 1 and parameter 838 EDS Data type must be
set to Errata 1 and power must be re-cycle.

VLT 2800 US version with DeviceNet

Product Code
232
233
234
235
236
237
238
283
284
285
286
287
288
289
290
291
292
293
294
36
Drive Model Drive Rating
kW (HP)
VLT 2803 0.37 (0.50)
VLT 2805 0.55 (0.75)
VLT 2807 0.75 (1.00)
VLT 2811 1.10 (1.50)
VLT 2815 1.50 (2.00)
VLT 2822 2.20 (3.00)
VLT 2830 3.70 (5.00)
VLT 2805 0.55 (0.75)
VLT 2807 0.75 (1.00)
VLT 2811 1.10 (1.50)
VLT 2815 1.50 (2.00)
VLT 2822 2.20 (3.00)
VLT 2830 3.00 (4.00)
VLT 2840 4.00 (5.00)
VLT 2855 5.50 (7.50)
VLT 2875 7.50 (10.00)
VLT 2880 11.0 (15.00)
VLT 2881 15.0 (20.00)
VLT 2882 18.5 (25.00)
®
VLT 2800 / FCD 300 DeviceNet
Start RS Networx and go online and the VLT
2800/FCD 300 will be shown as a grey box as
unregistered device. Click on the VLT 2800/FCD
300 and go to Tools and choose EDS Wizard. Click
on next by the EDS wizard and choose Create an
EDS file. RS Networx will now start to create an
EDS file from the VLT frequency converter.
To upload EDS files please visit www.Dan-
fossDrives.com
Voltage
200 - 240 V
200 - 240 V
200 - 240 V
200 - 240 V
200 - 240 V
200 - 240 V
200 - 240 V
380 - 480 V
380 - 480 V
380 - 480 V
380 - 480 V
380 - 480 V
380 - 480 V
380 - 480 V
380 - 480 V
380 - 480 V
380 - 480 V
380 - 480 V
380 - 480 V
MG.90.B2.02 - VLT is a registered Danfoss trade mark
EDS File Name
