XBee API mode

Supported frames

Support for API frame types depends on the type of XBee you are using. The 802.15.4 XBee modules
included in this kit support the following API frames:
Transmit data frames are sent through the serial input, with data to be transmitted wirelessly to
remote XBees:
API
ID Frame name
0x08 AT Command
0x09 AT Command Queue
Parameter Value
0x10 Transmit Request
0x11 Explicit Addressing
Command Frame
0x17 Remote AT Command
Request
0x21 Create Source Route
0x24 Register Joining
Device
Receive data frames are received through the serial output, with data received wirelessly from
remote XBees:
API
ID Frame name
0x88 AT Command Response
0x8A Modem Status
0x8B Transmit Status
0x90 Receive Packet
0x91 Explicit Rx Indicator
0x92 IO Data Sample Rx
Indicator
0x94 XBee Sensor Read
Indicator
XBee® Zigbee® Mesh Kit
Description
Queries or sets parameters on the local XBee
Queries or sets parameters on the local XBee without applying
changes
Transmits wireless data to the specified destination
Allows Zigbee application layer fields (endpoint and cluster ID) to be
specified for a wireless data transmission
Queries or sets parameters on the specified remote XBee module
Creates a source route in the module
Registers a module with the Trust Center
Description
Displays the response to previous AT command frame
Displays event notifications such as reset, association,
disassociation, and so on.
Indicates wireless data transmission success or failure
Sends wirelessly received data out the serial interface (AO = 0)
Sends wirelessly received data out the serial interface when
explicit mode is enabled (AO 0)
Sends wirelessly received IO data out the serial interface
Sends wirelessly received sensor sample (from a Digi 1-wire
sensor adapter) out the serial interface
Supported frames
