Zigbee communication in depth
3. When the prompt (>>) displayed after scanning the network, write the name of the remote
node to get its neighbors. The output of the application should be similar to the following:
+----------------------------------------------+
|
+----------------------------------------------+
WARNING:
Jar version = RXTX-2.2pre1
native lib Version = RXTX-2.2pre2
Local XBee: COORD
Scanning the network, please wait... Devices found.
Type the node name to retrieve its neighbor table and press <ENTER> (only
<ENTER> to finish):
- ROUTER_1
- ROUTER_2
>> ROUTER_1
Total number of neighbors: 2
Neighbor: 1
-----------------------------------
PAN ID:
64-bit address: 0013A20040DA9D05
16-bit address: 0000
Device type:
Relationship:
Join requests:
Tree depth:
LQI:
Neighbor: 2
-----------------------------------
PAN ID:
64-bit address: 0013A20040DA9D2B
16-bit address: 7EF4
Device type:
Relationship:
Join requests:
Tree depth:
LQI:
#################################################
Type the node name to retrieve its neighbor table and press <ENTER> (only
<ENTER> to finish):
- ROUTER_1
- ROUTER_2
>>
Step 8: Section summary of explicit data and ZDO
In this section, you learned the following:
XBee® Zigbee® Mesh Kit
Explicit Data Sample
RXTX Version mismatch
0000000000002015
Coordinator (0)
Parent (0)
Unknown (2)
0
255 / 255
0000000000002015
Router (1)
None of parent, child, sibling (3)
Unknown (2)
15
255 / 255
Examples: explicit data and ZDO
|
