Inputs and outputs
2. Use XCTU to configure the following parameters:
Param XBee A
ID
2015
JV
—
CE
Enabled
[1]
NI
COORD
AP
API
Enabled
[1]
D4
—
Note The dash (—) in the table means to keep the default value. Do not change the default
value.
3. Write the settings of all XBee modules with the Write radio settings button
the Radio Configuration section.
Step 4: Create a Java project
Option 1: Eclipse
a. Select File > New, and click the Java Project.
b. The New Java Project window appears. Enter the Project name.
c. Click Next.
or
Option 2: NetBeans
a. Select File > New project....
b. The New Project window appears. In the Categories frame, select Java > Java Application
from the panel on the right, and click Next.
c. Enter the Project name and the Project Location. Clear the Create Main Class option; you will
create this later.
XBee® Zigbee® Mesh Kit
XBee B Effect
2015 Defines the network that a radio will attach to. This must be
the same for all radios in your network.
Enabled Verifies if a coordinator exists on the same channel to join
[1] the network or to leave if it cannot be found.
— Sets the device as coordinator.
Defines the node identifier, a human-friendly name for the
ROUTER
module.
The default NI value is a blank space. Make sure to
delete the space when you change the value.
Enables API mode.
API
Enabled
[1]
Digital Sets the DIO4/AD4 pin as Digial Output High in XBee B. The
Out, High LED is connected to this pin.
[5]
Example: send digital actuations
at the top of
122
