2. Use XCTU to configure the following parameters:
Param XBee A
XBee B XBee C
ID
2015 2015 2015
JV — Enabled Enabled
[1] [1]
CE Enabled — —
[1]
DH — 0 0
DL — 0 0
NI COORD ROUTER END_
DEVICE
AP API API API
enabled enabled enabled
[1] [1] [1]
SP 1F4 1F4 1F4
SM — — Cyclic
sleep
[4]
Effect
Defines the network that a radio will attach to. This must be the same for all radios on your network.
Verifies if a coordinator exists on the same channel to join the network or to leave if it cannot be found.
Sets the device as coordinator.
Defines the destination address (high part) to transmit the data to. Use the address 0000000000000000
to address the coordinator.
Defines the destination address (low part) to transmit the data to. Use the address 0000000000000000
to address the coordinator.
Defines the node identifier, a human-friendly name for the module.
The default NI value is a blank space. Make sure to delete the space. when you change the
value.
Enables API operating mode.
Defines the duration of time spent sleeping. 1F4 (hexadecimal) = 500 (decimal) x 10 ms = 5 seconds.
Enables the cyclic sleep mode.
