Zigbee communication in depth
Param XBee A
ID 2015
JV —
CE Enabled
[1]
NI COORD ROUTER_
AP API
enabled
[1]
Note The dash (—) in the table means to keep the default value. Do not change the default value.
3. Write the settings of all XBees with the Write radio settings button at the top of the Radio
Configuration section.
To get the neighbors of a remote node, go to
Step 4: Get neighbors: create a Java project
Create an empty Java project named using Eclipse or NetBeans with the following project
name:XBeeExplicitData.
Option 1: Eclipse
a. Select File > New, and click the Java Project.
b. The New Java Project window appears. Enter the Project name.
c. Click Next.
or
Option 2: NetBeans
a. Select File > New project....
b. The New Project window appears. In the Categories frame, select Java > Java Application
from the panel on the right, and click Next.
c. Enter the Project name and the Project Location. Clear the Create Main Class option; you will
create this later.
XBee® Zigbee® Mesh Kit
XBee B XBee C Effect
2015 2015 Defines the network a radio will connect to. This
parameter must be the same for all radios on your
network.
Enabled Enabled Verifies if a coordinator exists on the same channel to join
[1] [1] the network or to leave if it cannot be found.
— — Sets the device as coordinator.
ROUTER_ Defines the node identifier, a human-friendly name for the
1 2 module.
API API Enables API mode.
enabled enabled
[1] [1]
Step 4: Create a Java project
Examples: explicit data and ZDO
The default NI value is a blank space. Make
sure to delete the space when you change the
value.
project.
