Zigbee communication in depth
Size
Name (bits) Value
Extended 64
PAN ID
Extended 64
Address
Network 16
Address
Device Type 2
Receiver On 2
When Idle
Relationship 3
Reserved 1
Permit 2
Joining
Reserved 6
Depth 8
LQI 8
The entry in the router's neighbor table corresponds to the coordinator of the network.
Once you have finished, click the Close the serial connection
XBee® Zigbee® Mesh Kit
14 20 00 00 00 00 00 00 The 64-bit extended PAN ID of the neighboring
15 9D DA 40 00 A2 13 00 The 64-bit address of the neighboring device.
00 00
04
02
Set to 0
00
FF
Examples: explicit data and ZDO
Description
device.
The 16-bit address of the neighboring device.
The type of neighbor:
0x0 – Zigbee coordinator
0x1 – Zigbee router
0x2 – Zigbee end device
0x3 – Unknown
Indicates if the neighbor's receiver is enabled
during idle times:
0x0 – Receiver is off
0x1 – Receiver is on
0x2 – Unknown
The relationship of the neighbor with the remote
device:
0x0 – Neighbor is the parent
0x1 – Neighbor is a child
0x2 – Neighbor is a sibling
0x3 – None of the above
0x4 – Previous child
Set to 0.
Indicates if the neighbor is accepting join requests:
0x0 – Neighbor not accepting joins
0x1 – Neighbor is accepting joins
0x2 – Unknown
The tree depth of the neighbor device. A value of
0x00 indicates the device is the Zigbee coordinator
of the network.
The estimated link quality of data transmissions
from this neighboring device.
