2. Use XCTU to configure the following parameters:
Param XBee A XBee B
ID
2015 2015
JV — Enabled
[1]
CE Enabled —
[1]
DH — 0
DL — 0
NI COORD ROUTER_
1
AP API API
enabled enabled
[1] [1]
D4
— Digital
Input [3]
XBee C Effect
2015 Defines the network that a radio will attach to. This must be the same for all radios in your
network.
Enabled Verifies if a coordinator exists on the same channel to join the network or to leave if it cannot be
[1] found.
— Sets the device as coordinator.
0 Defines the destination address (high part) to transmit the data to. The address
0000000000000000 can be used to address the coordinator.
0 Defines the destination address (low part) to transmit the data to. The address
0000000000000000 can be used to address the coordinator.
ROUTER_ Defines the node identifier, a human-friendly name for the module.
2
The default NI value is a blank space. Make sure to delete the space when you change
the value.
API Enables the API operating mode.
enabled
[1]
Sets the DIO4/AD4 pin as digital input in the senders. This pin is connected to a button.
Digital
Input [3]
