To set the home position of the machine to the upper left corner of the engraving area, place the
material (in this example, the cell phone cover) on the engraving table and secure it. Install a cutter and
set it so that the cutter tip extends below the nose cone and can easily be seen. It is best to use a cutter
with a defined point when performing a job setup, such as the diamond drag cutter used here. The
picture below shows a 2" x 1" piece of tape applied to the material so that it is easier to reference the
corner of the engraving area and get the positioning correct.
In the Vision 9 software, select the Jogger icon form the top toolbar.
Select Connect, then use the Arrow buttons to move the spindle over your material until the cutter tip is
pointing to the upper left corner of the area to be engraved.
