16 Vision Express User Manual
3.2.1

Direct Connection to Computer

Direct Connection to Computer Using Crossover Cable
Once the machine is connected directly to your computer's network port with the crossover cable (the
gray colored cable), turn the machine on. The power switch for the Vision Express is located on the
power supply box for the machine. Once the machine has initialized (an audible "bump" will indicate
that initialization is complete), plug the supplied Vision USB drive into an available USB port on your
computer.
NOTE - This installation is performed on a Windows 7 PC. For Windows XP, Windows 8, Windows 8.1
or Windows 10, the screens are slightly different.
The computer will recognize the USB drive
Select Open folder to view files.
and the following screen will appear.
Select Continue without scanning.
