The indicator light above the Start Button indicates the status of the machine with the following:
Flashes Twice - Ready Status - When the machine is first powered up, after approximately 10 - 15
seconds, the drive motors will receive a power up signal from the processor and you may hear a very
light "bump" as they receive power. The Start Button Indicator light will repeat a pattern of flashing
twice. The machine is ready to receive a file.
Steady Flashing - File Ready to Engrave - If the Start Button Indicator Light flashes at a slow, steady
rate, a file is ready to run.
Rapid Flashing - Emergency Stop Depressed - If the Start Button Indicator Light rapidly flashes, the
Emergency Stop Button has been depressed. If the Emergency Stop was pressed to prevent the
machine from continuing operation (if there was a problem with material of file setup), after resolving
the problem, turn the Emergency Stop Button clockwise (as viewed from the top of the machine) to
release the stop button. To move the motion system to the home position, press the Pause Button. To
recall the last job sent, press the Start Button, then press Start again to begin engraving.
Light OFF - File Complete - After running the file, the Start Button Indicator Light will turn off.
HINT - if the user wishes to re-run the last completed file, press the Start Button to re-call the last
file and the indicator light will begin steady flashing. Press the Start Button to run the file. If the
machine was powered off, all files are erased and pressing the Start Button will not recall any files.
Flashes Three Times - This indicates that a file has been Paused. If the user presses the Start Button,
the file will resume from the position where it was paused. If the Pause Button is pressed again, the
machine will return to the home position. To re-call the last file, press the Start Button once. To re-run
the last file, press the Start Button again.
Re-Home Function
In order to verify or Re-Home the Express engraver - 1) If no files have been sent to the engraver,
press the Pause Button, or 2) If a file has been sent to the engraver, press the Pause Button once,
then press and hold the Pause Button. After re-homing the engraver, the status light will turn off.
