Maintenance 109
5.2

Lubrication

Materials Needed
3-in-1 oil
Teflon-free Silicon Spray
Allen Wrench Set
Paper Towels
Isopropyl Alcohol
Procedure
Portions of this procedure are illustrated with the top cover installed. Although it is not necessary to
remove the cover for cleaning and lubrication, it will make access to the various motion system
components much easier.
Spindle Cover Removal
To remove the spindle cover, slide the cover up. Squeezing the sides of the cover will facilitate removal.
