Vision Engraving & Routing Systems Express User Manual page 89

Step by Step Operation 89
Once the Hatch Fill has been adjusted, select Close from the toolbar menu. The image is ready to be
sent to the engraver. You may want to change the hatch fill color to match the color of the outline,
although it is not necessary.
Filling Outline Text
Hatch fills can be applied to outline text, but not single line text. In the below example, Arial text was used
by selecting the Frame Text Compose icon and clicking in the middle of the plate to create the text as
shown.
