Vision Engraving & Routing Systems Express User Manual page 67

Step by Step Operation 67
Each line of text can be independently set for font and size. Highlight the text to be changed, then from
the font list on the top toolbar, choose the font to be used for the selected text and double click on the
font name. If the size or other parameters need to be revised, use the toolbar fields to modify the font
style. Please note that in this example, the Width Compression for the text was adjusted. In order to
adjust the Width Compression, select the text, click on the Toolbar Mode icon (shown below).
Select Frame mode.
Select all text and select the Width Compression Mode by clicking on the drop down list (as shown).
© 2015 Vision Engraving & Routing Systems
