Step by Step Operation 63
Select Connect to enable communication with the engraver, then click on the move arrows to move the
cutter over the material that was placed on the t-slot table. Lower the cutter/spindle with the Z Down
button until the tip of the burnishing cutter comes in contact with the material. Once the burnishing cutter
just touches the material, move the Z Down approximately 0.03 - 0.05 inches (0.5 - 1.0 mm) to preload
the EZ Rider spring. Select the Set Surface button in the Jogger window to set this as the Z position on
the engraver. Once the surface has been set, select Go to Home, select Disconnect and close the
Jogger Window.
In the following example job, a burnishing file will be set up and run on coated brass material.
