SpectraLink NetLink e340 Configuration And Administration Manual page 58

SpectraLink Corporation
Message Description
Select License The correct protocol has not been selected
from the license set.
Server Busy Handset is attempting to download from a
TFTP Server that is busy downloading other
devices and refusing additional downloads.
Skt Open Fail Socket open fail. Occurs when the Handset
tries to connect to the PBX but there is no
response. If resiliency is active, the handset
will keep trying.
Storing Config Handset is storing changes to handset
configuration.
SVP Service Rej. The NetLink SVP Server has rejected a
request from the handset
System Busy y...y = SVP Server IP Address
yyy.yyy.yyy.yyy SVP Server has reached call capacity.
System Locked NetLink SVP Server is locked
(with Busy Tone)
System Gateway is locked
TCP Rcv Timeout If the PBX has failed, this message may
display briefly as the handset tries to connect
to the backup PBX in a resilient setting. This
message may be replaced by the SKT Open
Fail message if the handset is unsuccessful
at connecting with the backup PBX or if
resiliency is not programmed.
TFTP ERROR(x):yy A failure has occurred during a TFTP software
download. (x) = The file number which was
being downloaded; yy is an error code
describing the particular failure. Possible
error codes are:
01 = TFTP server did not find the requested
file.
02 = Access violation (reported from TFTP
server).
07 = TFTP server reported "No such user"
error.
81 = File put into memory did not CRC.
FF = Timeout error. TFTP server did not
respond within a specified period of time.
PN: 72-1084-02-E.doc
Configuration and Administration—NetLink e340/i640 Wireless Telephone
Mitel Networks 3300 and SX-200 ICP and 5220 IP Phone emulation
Action
Using the administrative menus, select one
license from the set to allow the phone to
download the appropriate software.
None, the handset will automatically retry
the download every few seconds.
If the PBX is inoperative and resiliency is
not active or the handset cannot locate a
backup PBX, turn off the handset and
repair the primary PBX. Note that it may be
advisable to reconfigure the backup PBX to
be the primary PBX if the repair is more
time-consum-ing than the reconfiguration.
None. Informational only. The handset may
display this briefly following a
configuration change or software
download.
The handset will restart and attempt to re-
register with the SVP Server, which should
fix the problem. Report to your
administrator if it keeps happening.
All call paths are in use, try the call again
in a few minutes.
Try call again later, system has been
locked for maintenance
Try the call again, system has been locked
for maintenance
Wait for the handset to cycle through
attempts to connect to the backup PBX.
See SKT Open Fail above.
Error code 01, 02 or 07 - check the TFTP
server configuration.
Error code 81, the handset will attempt to
download the file again.
For other messages, power off the handset,
then turn it on again to retry the download.
If the error repeats, note it and contact
SpectraLink Technical Support.
Page 58
