3.3

Startup Sequence

The handset goes through an initialization sequence at startup. The line icons 1-9
display and count down as the handset steps through this sequence. This is usually
very rapid. If there is any difficulty at any step that prevents initialization from
continuing, an error message will display and the related icon(s) will stay on. Please
see the error table at the back of this document for instructions on how to handle
error messages that occur during initialization.
Icon The icon(s) shown in bold turns off when:
123456789 The handset has located and authenticated and associated with at least one AP, and is
proceeding to bring up higher-layer networking functions.
12345678 The handset is either configured for Static IP, or if configured for DHCP the DHCP discovery
process has started.
1234567 If DHCP is configured, a DHCP response was received which contains a good DNS server
configuration.
123456 Note: Only valid on non-SRP protocol. Indicates one of the following:
Static IP configuration, or
SVP Server address found in DHCP response, or
SVP Server address found via DNS lookup.
12345 All networking functions are complete (notably, DHCP) and the handset is proceeding with
establishing the SRP link to the SVP Server.
1234 The SRP link is established, all network stack initialization is complete, proceeding with
application-specific initialization.
123 The link between the handset and the PBX is established.
12 The handset has registered to the PBX.
12 Requested if PIN had not previously been entered, if PIN has been cleared, or if MAC address
Please Enter PIN not entered in the DN con-figuration table on the PBX.
The PIN may be up to 18 characters. The first few are a secret number defined at the PBX, the
rest are the extension of this handset. User must enter a valid PIN number and press the
Send softkey. Alternately, the handset may be configured in the DN configuration table on
the PBX.
Note: there is no timeout and the user must reboot if an invalid PIN is entered.
1 The handset has received a definition string for each of the 14 programmable buttons. If the
handset hangs up at this point, there has been an undetected error in the retrieval process
and the handset will need to be rebooted.
(no icons)
Initialization is complete. The handset is in standby mode ready to receive and place calls.
EXT. XXXXX
