9.3

Syslog Mode

A syslog server must be present on the network in order for the handset to send the
log messages and have them saved. The syslog server will be found with DHCP
option 7 if the handset is using DHCP. If static addresses are configured, the syslog
server's IP address can be configured statically in the Admin menu.
If the syslog server address is blank (000.000.000.000 or 255.255.255.255)
or the handset is using DHCP and no option 7 is received from the DHCP
server, the handset will not send any syslog messages.
Admin menu options:
• *
turns syslog off.
Disabled
•
causes the handset to log only events that we consider to be an error (see
Errors
below).
•
logs all errors plus also some other interesting events (see below).
Events
•
logs all the above plus a running stream of other quality information (see
Full
below).
The table below lists the syslog messages and which level of logging will produce
them:
Message type
Failed Handoff
Successful Handoff
Security Error
Call Start/End
Audio stats
Audio error threshold exceeded
Radio stats
Radio error threshold exceeded
All syslog messages will include:
• Date and time (to 1/100th of second) since handset power on (currently set to
Jan-1 00:00.00)
• Handset's MAC address
• Handset's IP address
• Sequence number
The table below lists the additional items in each Message type:
Failed Handoff
(Sent whenever the handset attempted to
handoff, but failed trying.)
PN: 72-1084-02-E.doc
Configuration and Administration—NetLink e340/i640 Wireless Telephone
Mitel Networks 3300 and SX-200 ICP and 5220 IP Phone emulation
Errors Events
Yes Yes
No Yes
Yes Yes
No Yes
No No
Yes Yes
No No
Yes Yes
Failed AP MAC
Failed AP signal strength
Current AP MAC
Current AP signal strength
Failure reason
Full
Yes
Yes
Yes
Yes
Yes (every 5 secs)
Yes
Yes (every 5 secs)
Yes
Page 46
