Screen 2
• Jitter (Jitter), average error or "wobble" in received packet timing, in
microseconds
• Last successful transmit data rate (LastRate)
• Gateway type (GatewyType)
Where:
• mnemo : A mnemonic that indicates what type of gateway is being used
• SawA2: All handsets are rate limited to 2Mb because a 500 series NetLink
handset is on the network.
• 2Mb: non-NetLink SVP Server Gateway system (handsets are limited to 2Mb if
the NetLink SVP Server is not used.)
• 11Mb: Gateway with NetLink SVP Server and no 500 series NetLink Wireless
Telephones. This system can run at the full 11Mb/s speed.
Screen 3
Screen 3 contains a list of the APs that are heard and the following parameters from
each AP:
• Indicator as to whether this is the current AP or an index into the list of other
APs heard
• Last 2 octets of the MAC address of the AP
• Channel number
• Signal strength
• Either the 802.11 Association ID from the current AP or a mnemonic for the
reason code indicating why the handset didn't hand off to this other AP.
Where:
• C: Indicates the AP that the handset is currently using
• n: Indicates an index into the list of other APs, where n is equal to 1, 2, or 3
• mmmm: This hexadecimal number is the last 2 octets of this AP's MAC address
• ch: Channel number the AP is configured on
• -ss: Signal strength for the AP in dBm
• aid: The Association ID for the currently associated AP
• mnem: A mnemonic that indicates why the handset didn't hand off to this other
AP:
Unkn: Reason unknown
PN: 72-1084-02-E.doc
Configuration and Administration—NetLink e340/i640 Wireless Telephone
Mitel Networks 3300 and SX-200 ICP and 5220 IP Phone emulation
J i t t e r
L a s t R a t e
G a t e w y T y p e
C : m m m m c h
1 : m m m m c h
2 : m m m m c h
3 : m m m m c h
n n n n n
n n n n n
m n e m o
- s s a i d
- s s m n e m
- s s m n e m
- s s m n e m
