Printing
After each measurement with the plusoptiX A12x, any number of labels for documenting the
measurement results can be printed out. To do so, align the plusoptiX A12x with the infrared
receiver of the printer. The distance between plusoptiX A12x and the printer should be
approximately 1 m (3,28 ft). As soon as you touch the printer symbol on the screen of the
plusoptiX A12x, the data is transmitted and a label is printed out. To confirm the
transmission, a blue control lamp lights up in the infrared receiver. Keep the device directed
at the printer until the blue control lamp turns off.
Note:
If the infrared transmission is interrupted during a printing order the print-out of
the label is also interrupted. To obtain a complete print-out a new printing order
has to be sent.
Cleaning
If the print quality should deteriorate it is necessary to clean the printing head, paper sensor,
tear-off edge and drive roller. To do so:
- Open the cover of the paper compartment and remove the paper roll.
- If paper dust has accumulated in the paper compartment, clean it out with a vacuum
cleaner with fitted brush
- Clean the printing head and the drive roller with an ear bud lightly soaked in
isopropanol alcohol (IPA).
Tear-off edge
Paper sensor

Figure 21: Cleaning the plusoptiX P12

Page 67/68
Drive roller
Printing head
