4.1.9 Save and print a measurement report

A measurement report documents the measurement results and the last picture taken during
the measurement. If an anonymous measurement was performed, the measurement report
has to be saved manually by touching the printer button (1) in the navigation bar. After
touching the printer button (1) the patient data entry template is displayed by plusoptiX A12C
(see chapter 3.3 "Entering patient data (only plusoptiX A12C)"). PlusoptiX A12R displays a
input field instead. Fill in the patient information that should be printed on your measurement
report and then touch the green checkmark (2). The measurement report is then saved.
Note:
The connection of an external keyboard is necessary for the input of the patient
data on the plusoptiX A12R.
To be able to allocate these PDF files to individual patients, the patient information is part of
the file name. If a patient ID is entered instead of or in addition to the patient name, this patient
ID forms part of the file name instead of the patient name. A date and time stamp is also
included.
Example: Smith_Emily_20140527-114102.pdf
If patient data was entered or retrieved with plusoptiX A12C, a measurement report is
automatically saved on the SD card at the end of the measurement.
10.0

Figure 14: Measurement report (plusoptiX A12C)

1)
Page 41/68
2)
Patient
information
