A sample of the information printed on the self-adhesive label is shown in figure 15:
Name or ID
OD
measurement
values
Software
version
With every successful measurement a measuring report is saved on the SD card as PDF-file
(see chapter 4.1.9 "Save and print a measurement report"). In order to then print out the
measuring report on your network- or workplace printer, you must open the PDF-file of the
measuring report from your workplace computer.
For this there are three different possible methods of access available:
Connection via your DHCP WLAN server – see chapter 4.1.4 (only plusoptiX A12C)
-
File access with URL:
\\plusoptix12\pdf (Windows Explorer),
smb://plusoptix12/pdf (Apple Finder)
Connection via Mini-USB-cable – see chapter 4.1.12
-
File access with URL: removable medium:\pdf
- Connect SD card directly to your workplace computer
Start Windows Explorer or Apple Finder and open the file to be printed. You can print out the
file on any optional printer connected with your network or workplace computer.
Note:
The connection over a Mini-USB cable is available for all A12x devices from the
supplement "01F" in the serial number (Example: S/N 120xA-01F-xxxx xxxx).
Note:
If the workplace computer displays the error message "Access denied", close
Windows Explorer or Apple Finder and then restart the program.
First name Last name
OD
+0,75 dpt Sphere
-0,75 dpt Cylinder
176° Axis
5.8 mm Ø pupil
Pupil distance
Gaze asymmetry
Ver. 6.1.10.0
www.plusoptix.de

Figure 15: Self-adhesive label sample

Page 43/68
*31/12/2013
Date of birth
OS
+0.25 dpt
-2.25 dpt
87° OS
4.5 mm
measurement
56 mm
7.6 °
values
Measurement
17/07/2015
date
