Once you have inserted the batteries, close the cover of the battery compartment and place
the printer in front of you. Now connect the medical power supply with the power cable to the
power socket and check if it is live (the green LED on the top of the medical power supply is
on). Following this, connect the medical power supply to the printer.
The inserted batteries are now automatically charged. During the charging process, the red
control lamp in the infrared receiver is on and turns off as soon as the batteries are
completely charged. The maximum battery charging time of the supplied batteries is 4.5
hours.
Inserting paper
Open the paper compartment by slightly lifting the unlocking lever on the paper compartment
cover.
Unwind a little paper from the roll, so that approx. 1 inch protrudes from the paper
compartment. Ensure that the paper layers remain tightly wrapped about the roll core. Then
place the paper roll in the paper compartment as shown. After this, close the cover of the
paper compartment by pressing down on the cover. The cover engages audibly.
Note:
Use only original paper available from Plusoptix or a Plusoptix authorised dealer.
Switching printer on and off
To switch on, briefly press the On button. The printer starts immediately and is ready for
operation as soon as the status lamp flashes green.
When not used, the printer automatically switches off after approximately 10 minutes. To
switch it off manually, keep the Off button depressed for 3 seconds.

Figure 20: Open cover and insert paper
