4.1.7 Import patient data (only plusoptiX A12C)

Patient data (i.e. a roster of patients) can be imported from a CSV table via the USB port.
Data fields in a CSV table to be imported have to:
- be separated using the separator "," or ";" as selected in Basic settings
- contain five separators (the separator after "contact" is an optional addition)
- adhere to this sequence: last name, first name, date of birth, patient ID, location, contact
- include either last name, first name and date of birth or patient ID, location and contact
information are always optional
- use same date format as set in Date & time settings (e.g. 01/31/2013 or 31.01.2013)
A
1 Family name
2 Smith
3
4 Smith
5
Note:
The column titles in the first row are not imported. Although a patient's data is
located in the first row of the CSV table, this first set of patient data is not imported.
Save your CSV table on an USB storage device and connect it to the device. Then touch Data
import (2) in Settings (1). A list of all CSV tables that exist on the USB storage device will be
displayed on screen. Select the CSV table to be imported and confirm your selection by
touching Checkmark button in navigation bar (3).
Before patient data is imported, the device automatically checks whether the data records are
consistent (e.g. no numerical values in the "last name" field). However, data entries that have
been swapped around (e.g. first name instead of last name) are not automatically detected. As
a result, you are prompted to check whether the patient data is displayed in the correct
sequence. If this is the case, confirm the data import by touching Checkmark button (3) in
navigation bar.
Note:
Imported patient data is always added to the entries already stored in the
database. When importing patient data, no data is deleted.
B C
First name Date of birth
John 02/28/2010
Emily 03/08/2008
06/18/2009

Figure 12: Example of a CSV table

1) 2)
Page 39/68
D E
Patient ID Location
0123456789
AB12CD24 London
A-12-B-34-C Exam room
3)
F
Contact
mh@mail.uk
020-123456
