If the device is already connected to a WLAN, a green Checkmark (1) is displayed instead of a
Warning symbol. The name of the WLAN is marked in orange, and the IP address is displayed
next to the password (2).
WLAN active IP address

Screenshot 16: Active WLAN connection

If WLAN connection is malfunctioning, a Warning symbol is displayed below to the WLAN
symbol (3).
Warning symbol
Screenshot 1: Viewing an active network connection

Screenshot 17: WLAN error messages

Warning symbol (4) indicates that password is incorrect.
Warning symbol (5) indicates that DHCP server has not allocated an IP address.
Warning symbol (6) indicates that DHCP server is out of range or that no WLAN network
connection is established.
1) 2) 3) 4) 5) 6)
