Screenshot 22: Generate A Report - PLUSOPTIX A12C User Manual

Note:
If you restore a database, a backup copy of the existing database is first saved to
the USB storage device. The existing database is then overwritten with the
database to be restored. The two databases (backup copy on the USB device and
the existing database in the device) are not merged.
To create a report, first connect an USB storage device to the device and then define the
scope of the report using data filters. To save a report, touch Checkmark button (1) in the
navigation bar.
The filters have the following meaning:
(2) Report includes all successful measurements, i.e. measurement results are available.
(3) Report includes all aborted measurements, i.e. no measurement results were obtained.
(4) Report includes all patients with the set date of birth.
(5) Report includes all patients measured on the set date.
(6) Report includes all patients born (button (4) is active) or measured (button (5) is active) on
the set dates or between these dates.
(7) Report includes all measurements that were performed at the set examination location.
If you select filters that are active in screenshot 23 (active filters are highlighted in orange), a
CSV file with all inconclusive measurements at the examination location of Montevideo, that
took place in between 05/05/2013 and 05/08/2013 (both dates inclusive), will be created.
Note:
Reports are always saved as a CSV table. CSV tables can be processed by all
conventional spreadsheet programs.
1)

Screenshot 22: Generate a report

2) 3) 4)
Page 38/68
5) 6) 7)
