PLUSOPTIX A12C User Manual page 21

If you do not want to print patient data in the Measurement report, touch Checkmark button (1)
without entering any patient data. In this case Measurement report is saved anonymously.
If a SD card was inserted and patient data was entered before the measurement with
plusoptiX A12C, a measurement report will automatically be saved on the SD card (see
chapter 4.1.9 "Save and print a measurement report").
Note:
Whenever you touch Print button (2), an additional print job will be added to print
spooler. As soon as the compatible printer is connected (see chapter 4.1.10
"Compatible printers and network printing") it will print all print jobs in chronological
order.
Attention:
All print jobs in print spooler are deleted once device is switched off or switches off
for power saving automatically. Measurement reports saved to a SD-card are not
deleted when device is switched off or switches off for power saving.
Check measurement result screen
To measure the same patient again, simply press the Shutter once to return to Start screen
and a second time to start the next measurement for the same patient. You do not need to
touch the screen during this process. There is no need to re-enter the patient data.
Measurement results are displayed on screen immediately after
a measurement was performed. "Measurement completed" is
displayed in the status line.
After an inconclusive measurement, "Measurement aborted" is
displayed in the status line.
In this case a red error message is displayed above the status
line and you will find additional information in chapter 4.2.3
"Error messages when performing a measurement".
1) 2)
Page 21/68
