Screenshot 4: Entering A First Name - PLUSOPTIX A12C User Manual

Use the screen keypad to enter the patient data. Touch:
- the Caps Lock key (1) to switch back and forth between lower- and upper case typing
- the SYM key (2) to insert special characters
- the Backspace key (3) to delete the last character.
Please read chapter 4.1.14 "External mouse or keyboard" if you prefer this option for entering
data.
Once all necessary patient data has been entered, that is, either date of birth and first name
and last name, or date of birth and patient ID, the Checkmark button (4) in the navigation bar
is activated.
You can now either perform a measurement by pressing the Shutter or save the patient data
without performing a measurement. To save the data, simply touch the Checkmark button (4).

Screenshot 4: Entering a first name

1) 2)
Page 16/68
3) 4)
