L-Acoustics KARA MODULAR WST SYSTEM Rigging Procedures page 43

10. Separate the platform from KARA#1 as follows:
a. Remove both KARA-MINIBU front R-BLP.
b. If KARA-ANGARMEX are attached to the platform, remove both T-BLP from them.
Otherwise, remove both KARA-MINIBU rear R-BLP.
c. Separate the platform from KARA#1.
d. If KARA-ANGARMEX are attached to the platform, remove them by removing both KARA-MINIBU rear
R-BLP.
e. Re-insert the four R-BLP into the KARA-MINIBU holes.
KARA_SRM_EN_1-0
KARA#1
Rear extension configuration
without KARA-ANGARMEX
Front extension configuration
with KARA-ANGARMEX
Figure 46: Separating KARA-MINIBU from KARA#1
w w w . l - a c o u s t i c s . c o m
(x4)
c.
b.
e.
a.
(x2)
(x2)
c.
b.
