VERSION 1.0
a.
Figure 7: Checking the ARRAY#1 inter-enclosure attachments
3. Open the four KARA#1 arms as follows (repeat on both sides of the enclosure):
a. Remove the front top R-BLP from its storage hole, rotate the front arm up, slide it down, and lock it in place
by re-inserting the R-BLP into its link hole. Note: The front top storage and link holes are the same.
b. Remove the rear top R-BLP from its storage hole, slide the angle arm so as to align the cursor with angle
label 5°, and lock it in place by re-inserting the R-BLP into angle hole 1°/3°/5°/7.5°/10°.
It is recommended to select the 5° angle on the KARA intended to be attached to the KARA-
MINIBU; in that way the KARA#1 axis will be parallel to the KARA-MINIBU.
IMPORTANT
a.
L
KARA_SRM_EN_1-0
® ® ® ®
WST WST WST SYSTEM SYSTEM SYSTEM SYSTEM
kara- - - - minibu kara minibu
kara kara minibu minibu
KARA#1
KARA#2
KARA#3
ARRAY#1
Figure 8: Opening the KARA#1 arms
w w w . l - a c o u s t i c s . c o m
b.
0°
b.
L
