  • Page 1 owner's manual (EN)
  • Page 2 Document reference: X4r owner's manual (EN) version 1.0 Distribution date: June 5, 2023 © 2023 L-Acoustics. All rights reserved. No part of this publication may be reproduced or transmitted in any form or by any means without the express written consent of the publisher.

  • Page 3: Table Of Contents

    X4r point source with SB10r......................22 Rigging procedures............................25 Tools..............................25 Mounting X4r in a wall or in a ceiling with X4r inWall................26 Mounting X4r in a ceiling tile with X4r inTile.................... 30 Connection to LA amplied controllers........................ 34 Cabling schemes for X4r......................... 34 Cabling X4r............................
  • Page 4 SB6r..............................39 SB10r..............................40 X4r-inCW............................... 41 X4r-Screen.............................. 42 X-U4i..............................43 X4r-Tilescreen............................44 APPENDIX A: Recommendation for speaker cables....................45 APPENDIX B: Specications for custom rigging....................46...

  • Page 5: Safety

    Respect the Working Load Limit (WLL) of third party equipment. L-Acoustics is not responsible for any rigging equipment and accessories provided by third party manufacturers. Verify that the Working Load Limit (WLL) of the suspension points, chain hoists and all additional hardware rigging accessories is respected.
  • Page 6 This system is intended for use by trained personnel for professional applications. As part of a continuous evolution of techniques and standards, L-Acoustics reserves the right to change the specications of its products and the content of its documents without prior notice.

  • Page 7: Introduction

    X4r features a 1.4" diaphragm compression driver coaxially loaded by a 4" neodymium low-mid frequency transducer mounted in a closed cabinet. X4r operates from 120 Hz to 20 kHz and delivers a peak SPL of 116 dB. The coaxial transducer arrangement produces a 110° axisymmetric directivity with a smooth tonal response free of secondary lobes over the entire frequency range.

  • Page 8: Revision History

    Introduction Revision history version number publication date modication Jun. 2023 Initial version. X4r owner's manual (EN) version 1.0...

  • Page 9: System Components

    Refer to the LA2Xi / LA4X / LA7.16i / LA12X owner's manual for detailed instructions about the whole cabling scheme, including modulation cables and network. Rigging elements X4r-inCW In-wall or in-ceiling mounting accessory for X4r X-U4i Adjustable U-bracket for X4i Screens...
  • Page 10 System components System component illustrations Cables 2 × 2.5 mm² cable custom 2-point speakON cable Rigging accessories X4r-inCW X-U4i Screens X4r-Screen X4r-Tilescreen Software applications Soundvision LA Network Manager X4r owner's manual (EN) version 1.0...

  • Page 11: Electro-Acoustical Description

    Electro-acoustical description Electro-acoustical description Directivity X4r generates an axisymmetrical directivity pattern of 110°. Dispersion is dependant on the installation environment. Preset description [X4] [X4_60] [X4_MO] outputs channels routing gain delay polarity mute OUT 1 IN A 0 dB 0 ms...

  • Page 12: Connectors

    Connectors IN LINK 2 × 2-point screw terminal X4r is provided with a connector sealing plate with two cable glands for 2.5 mm cables. If only one connector is used, replace one cable gland with the protective plug. Pass the cables through the cable glands before connecting them to the screw terminals.

  • Page 13: Rigging System Description

    Rigging system description Rigging system description X4r is the recessed version of the X4i enclosure and is designed for in-wall or in-ceiling congurations. The front of the enclosure features a gasket to t against a screen. X4r features one M5 insert on each side to secure X4r-inCW for in-wall or in-ceiling congurations or X-U4i for congurations in ceiling tiles.
  • Page 14 X4r-inCW is secured to the drywall using the xing clamps. X4r-inCW is provided with a tether for secondary safety. An insert is available on both elements of X4r-inCW to secure the secondary safety tether and the tether of X4r-Screen. X4r owner's manual (EN) version 1.0...

  • Page 15: X4R-Screen

    X-U4i X-U4i is an adjustable U-bracket compatible with X4r. It can be used to mount one X4r in ceiling tiles with a threaded rod, using the Ø 11 mm / Ø 0.43 in hole. Ø 11 mm / 0.43 in...

  • Page 16: X4R-Tilescreen

    Rigging system description X4r-Tilescreen X4r-Screen is an acoustically transparent screen for congurations in ceiling tiles with X4r and X-U4i. X4r-Tilescreen is only compatible with 600×600 mm (2×2 ft) ceiling tiles. Eight holes are available on the sides of X4r-Tilescreen for secondary safety.

  • Page 17: Mechanical Safety

    The recessed system should always be implemented in a straight drywall. Risk of overloading the suspended ceiling When implementing one or multiple X4r-Tilescreen, make sure to respect the country's standards related to suspended ceilings. X4r-Tilescreen weight: 3.1 kg / 6.8 lb...

  • Page 18: Loudspeaker ConGurations

    Loudspeaker congurations X4r point source In this conguration, the X4r system operates over the nominal frequency range of the enclosure. The [X4] preset delivers a reference frequency response in short throw applications. X4r is driven by the LA2Xi / LA4X / LA7.16i / LA12X amplied controllers.

  • Page 19: X4R Point Source With Low-Frequency Element

    X4r point source with SB6r Closely coupled With SB6r and the preset [SB6_200], the bandwidth of the X4r system is extended down to 32 Hz and the system contour is reinforced by 9 dB at 50 Hz (peak low-end SPL).
  • Page 20 X4i = 0.6 ms SB6i = 0 ms Coupled With SB6r and the preset [SB6_100], the bandwidth of the X4r system is extended down to 29 Hz and the system contour is reinforced by 7 dB at 50 Hz (peak low-end SPL).
  • Page 21 Loudspeaker congurations Separated With SB6r and the preset [SB6_60], the bandwidth of the X4r system is extended down to 29 Hz and the system contour is reinforced by 9 dB at 50 Hz (peak low-end SPL). The preset [X4_60] provides optimal frequency coupling with the low-frequency element.

  • Page 22: X4R Point Source With Sb10R

    Loudspeaker congurations X4r point source with SB10r Closely coupled With SB10r and the preset [SB10_200], the bandwidth of the X4r system is extended down to 29 Hz and the system contour is reinforced (peak low-end SPL). in-ceiling/wall recommended max. 90 cm / 35 in...
  • Page 23 Loudspeaker congurations Coupled With SB10r and the preset [SB10_100], the bandwidth of the X4r system is extended down to 27 Hz and the system contour is reinforced (peak low-end SPL). in-ceiling/wall recommended max. 1.7 m / 5.6 ft reinforced contour...
  • Page 24 Loudspeaker congurations Separated With SB10r and the preset [SB10_60], the bandwidth of the X4r system is extended down to 25 Hz and the system contour is reinforced (peak low-end SPL). The preset [X4_60] provides optimal frequency coupling with the low-frequency element.

  • Page 25: Rigging Procedures

    Other manufacturers can be used. name reference distributor set of 6-point 1/4" sockets RL.NANO1 / R.360NANO FACOM torque screwdriver (2 - 10 N.m) A.404 FACOM level trim clip removal pliers X4r owner's manual (EN) version 1.0...

  • Page 26: Mounting X4R In A Wall Or In A Ceiling With X4R Inwall

    Rigging procedures Mounting X4r in a wall or in a ceiling with X4r inWall type of deployment wall-mounting ceiling-mounting rigging accessories X4r inWall, including: • X4r enclosure • X4r-inCW rigging accessory • X4r-Screen • cardboard cutting template additional material 2 M5×25 Torx screws (provided) 1 M4×12 Torx screw (provided)
  • Page 27 MAX: 151.5 x 151.5 mm min 30 mm / 1.2 in 2. Remove the placeholder screws on both sides of the enclosure. 3. Secure X4r-inCW to the enclosure, using the M5x25 Torx screws. 3 N.m 4. Prepare the cabling. Refer to Cabling X4r (p.36).
  • Page 28 7. Secure the enclosure assembly to the drywall using the clamps. Tighten the screws until the clamps are tightly secured against the drywall. Risk of damage Do not apply more than the indicated torque. 2 N.m 4 mm X4r owner's manual (EN) version 1.0...
  • Page 29 Rigging procedures 8. Secure the secondary safety tether and the tether of the screen to the top insert of X4r-inCW using the M4x12 Torx screw. 3 N.m 9. Align the barbed push fasteners with the frame holes and push the screen into place.

  • Page 30: Mounting X4R In A Ceiling Tile With X4R Intile

    T25 Torx bit min. number of operators X4r-Tilescreen is only compatible with 600x600 mm (2x2 ft) tiles (European standard). Secondary safety with X4r-Tilescreen Use the available holes to implement a secondary safety. 200 mm / 7.9 in of room are required between the main ceiling and the suspended ceiling or wall to install the enclosure assembly.
  • Page 31 3. Secure the X-U4i rigging bracket to the enclosure, with the front facing down, using the M5x16 Torx screws. Use the hole leaving the most space between the enclosure and the accessory. 5 N.m 4. Prepare the cabling. Refer to Cabling X4r (p.36). X4r owner's manual (EN) version 1.0...
  • Page 32 7. Lower the enclosure assembly by moving down the bottom nut until the front gasket presses on the screen. Risk of overloading the suspended ceiling Do not let the enclosure assembly rest on X4r-Tilescreen and the suspended ceiling. X4r owner's manual (EN) version 1.0...
  • Page 33 Rigging procedures 8. Tighten the top nut against the bracket to keep the enclosure assembly pressed against the screen. 9. Insert a security nut and tighten it against the bottom nut. X4r owner's manual (EN) version 1.0...

  • Page 34: Connection To La AmpliEd Controllers

    1+/1- For passive loudspeakers, the value corresponds to the number of enclosures in parallel on the output. For active loudspeakers, the value corresponds to the number of sections in parallel on the output. X4r owner's manual (EN) version 1.0...
  • Page 35 Connection to LA amplied controllers Two-channel speakON output custom cable 2.5 mm² cable 1+/1- 2+/2- 2.5 mm² cable X4r owner's manual (EN) version 1.0...

  • Page 36: Cabling X4R

    Procedure 1. Remove the two screws from the back of X4r. 2. Insert the cable through the cable gland. X4r owner's manual (EN) version 1.0...
  • Page 37 4. Insert the wires into the terminals and tighten the screws on the terminals with a at screwdriver. − 3 mm − 5. Secure the connector sealing plate to the enclosure. Apply a torque of 0.6 N.m. 0.6 N.m X4r owner's manual (EN) version 1.0...

  • Page 38: SpeciCations

    16 Ω Connectors IN: 1 × 2-point screw terminal LINK: 1 × 2-point screw terminal Rigging and handling 2 M5 inserts for X4r-inCW and X-U4i 2 M6 inserts for rigging accessory Safety 1 M6 insert for secondary safety Weight (net) 0.94 kg / 2.1 lb...

  • Page 39: Sb6R

    Peak level at 1 m under half space conditions using pink noise with crest factor 4 (preset specied in brackets). When integrated in-wall or in-ceiling with screen and connector sealing plate. SB6r dimensions 360 mm / 14.2 in 99 mm / 3.9 in 104.2 mm / 4.1 in X4r owner's manual (EN) version 1.0...

  • Page 40: Sb10R

    Peak level at 1 m under half space conditions using pink noise with crest factor 4 (preset specied in brackets). When integrated in-wall or in-ceiling with screen and connector sealing plate. SB10r dimensions 539 mm / 21.2 in X4r owner's manual (EN) version 1.0...

  • Page 41: X4R-Incw

    Specications X4r-inCW specications Description In-wall or in-ceiling mounting accessory for X4r Weight (net) 0.34 kg / 0.75 lb Material high grade steel with anti-corrosion coating X4r-inCW dimensions 54 mm / 2.2 in 33 mm / 1.3 in 85 mm / 3.3 in...

  • Page 42: X4R-Screen

    Specications X4r-Screen specications Description Wall or ceiling screen for X4r Weight (net) 0.3 kg / 0.66 lb Material steel with anti-corrosion coating acoustically neutral 3D fabric X4r-Screen dimensions 165 mm / 6.5 in 7 mm / 0.28 in X4r owner's manual (EN) version 1.0...

  • Page 43: X-U4I

    X-U4i dimensions 123 mm / 4.8 in 40 mm / 1.6 in 70 mm / 2.8 in 2 x Ø 6.6 mm / 0.26 in Ø 11 mm / 0.43 in X4r owner's manual (EN) version 1.0...

  • Page 44: X4R-Tilescreen

    Description Tile ceiling screen for X4r Weight (net) 3.1 kg / 6.8 lb Material steel with anti-corrosion coating acoustically neutral 3D fabric X4r-Tilescreen dimensions 595 mm / 23.4 in 13 mm / 0.51 in X4r owner's manual (EN) version 1.0...

  • Page 45: Appendix A: Recommendation For Speaker Cables

    8 Ω load 4 Ω load 2.7 Ω load Use the more detailed L-Acoustics calculation tool to evaluate cable length and gauge based on the type and number of enclosures connected. The calculation tool is available on our website: https://www.l-acoustics.com/installation-tools/...

  • Page 46: Appendix B: SpeciCations For Custom Rigging

    Take into consideration the number of inserts used, weight and center of gravity of enclosure(s), and resulting action forces. Prevent screws from loosening (threadlocker, spring washer...). X4r has 2 threaded M5 inserts and 3 threaded M6 inserts available for rigging. M5 inserts M6 inserts...
