Hardware Settings

Main
A pplies to
neoVI Yellow
W hile m ost neoVI settings are software program m able a few are set with hardware. The pull up resistors for the UART/ISO /Keyword 2k network
Setting
K and L line pull-up resistors
neoVI Documentation - (C) Copyright 2000-2019 Intrepid Control Systems, Inc.
Last Update: Thursday, July 09, 2009
Table 1 - Hardware Settings in the neoVI device
Bubble in Figure 1
A
Figure 1 - The K-Line pull-ups.
Instructions
Insert two 0.25 W resistors end to end with desired pull up values (510
O hm s are the factory default)
