High Speed CAN

High Speed CA N - neoVI
Main
A pplies to
neoVI Blue, neoVI Red, neoVI FIRE, neoVI Yellow, and ValueCA N
The neoVI high speed CAN channel is an ISO 11898 Dual W ire CAN Physical Layer (82C251) CAN channel. Lik e all CAN Channels, this channel has program m able baud rate/bit tim ing and CAN device m ode. This channel is
functionality equivalent to the m edium speed channel ex cept for that the neoVI circuits for high speed are optim ized.
According to the ISO 11898 specification, the ends of the CAN network cabling should be term inated. This is described in a separate topic.
