Specifications

Specifications
Main
A pplies to
neoVI Blue
Device
* Power Consum ption (typical) : 150m A @ 14.4 VDC
* Sleep Mode Power Consum ption (typical) : 3m A @ 14.4 VDC
* Power Supply: vehicle com patible 5.5-20.0 VDC
* Physical Dim ensions : 120 x 70 x 25 m m ( 4.8 " x 2.8 " x 1.0" )
* Weight: 113 g ( 4 oz )
* Non USB Tem perature Range: -40 to 85 C
* USB Tem perature Range: 0 to 70 C
* Vehicle Connector : 25 Pin m ale D-SUB
* Standard PC/Host Connectors: USB downstream , RS232 9PIN D-SUB Fem ale
* RS232 port capable of 115.2 k b, 57.6 k b, 38.4 k b, 28.8 k b, 19.2 k b, 9600 bps, and 4800 bps baud rates. Control lines include hardware handshak ing (RTS/CTS) and DTR acting as a DCE (Data Com m unication Equipm ent)
device.
* Warranty: O ne year lim ited warranty
* Firm ware: Field upgradeable design (flash EEPRO M)
* O n board Processing: 20 MIPS RISC based m ulti-controller design
* Ex pansion: Internal 5Mhz SPI interface and Ex ternal Device Tim estam p Synchronization
* Bicolor user notification LED (red-green) is user configurable or can change on network activity, trigger or IO pin.
* General Purpose IO : Seven IO configurable as input or output. Four configurable as 10 bit analog inputs. O ne configurable for ex ternal wak eup. ISO K and L Lines available as general purpose outputs. K Line available is
general purpose input.
* General Purpose IO rate report interval 1-100 m s or based on digital change. Analog input sam pling rate is 1 m s per channel.
* O n board 9-bit IC tem perature sensor with a range of -55 to 125 C (-67 to 257 F) .
* O n board non-volatile storage: 32KByte EEPRO M and MMC (Multim edia Card Card) slot for up to 64Mbytes of on board storage.
* EMI Shielded Enclosure
* Em ulation of General Motors VSI Interface via RS232
Networks - General
* Tim e stam ping to accuracy of 100uS on CAN network s, J1708 network , and Ford SCP network . 250 µs on Class 2 / J1850 VPW and ISO /KW 2K. Tim estam p rollover is greater than 1 year.
* Sim ultaneous operations on all network s with aggregate bandwidth perform ance of 2 m ega baud over USB.
* Transm it m essage double-buffering on all network s allows back to back m essage transm ission.
* Multiple hardware triggers allow bit-wise filter specifications on entire m essage (first 12 bytes for block type m essages)
* Generation of scan clock with correlated start m essage tim estam p for synchronization of ex ternal data acquisition equipm ent
* Device wak e up on network activity on any network .
High Speed CA N
* ISO 11898 Dual W ire CAN Physical Layer (82C251)
* CAN 2.0B active
* MCP2510 CAN controller with support for loop-back and listen-only operation.
* O ptim ized Rx and Tx circuitry
* Up to 1 M-Bit software selectable baud rate
* Graphical Bit Tim e/Baud Rate Calculator
Medium Speed CA N
* ISO 11898 Dual W ire CAN Physical Layer (82C251)
* CAN 2.0B active
* MCP2510 CAN controller with support for loop-back and listen-only operation.
* Up to 1 M-Bit software selectable baud rate
* Graphical Bit Tim e/Baud Rate Calculator
Low Speed Fault Tolerant CA N
* ISO 11519 Low Speed Fault Tolerant CAN Physical Layer (TJA1054)
* CAN 2.0B active
* MCP2510 CAN controller with support for loop-back and listen-only operation.
* Software selectable baud rate/bit tim ing up to lim itations of physical layer.
* Graphical Bit Tim e/Baud Rate Calculator
Single Wire CA N
* Single W ire CAN physical layer GMW 3089/ SAE J2411 (TLE6255)
* CAN 2.0B active
* MCP2510 CAN controller with support for loop-back and listen-only operation.
* High Speed Mode, High Speed Test Tool Mode, and High Voltage Wak eup support
