Terminating a Dual Wire CAN Network

Terminating a Dual Wire CA N Network - neoVI
Main
A pplies to
neoVI Blue, neoVI Red, neoVI FIRE, neoVI Yellow, and ValueCA N
Both the High Speed CAN and Medium Speed CAN channels require the ends of the CAN network to be term inated with a 120 ohm resistor.
Typically, if you are connecting to a ex isting CAN network these term ination resistors will be present. If you are building a test network you m ay have to install these resistors.
