neoVI and ValueCAN has the capability to sim ultaneously access a num ber of in-vehicle network s. These network s are shown in table 1 below.
Each network can be enabled or disabled (figure 1) in the hardware ex plorer.
Name
High Speed CAN
Medium Speed CAN
Single W ire CAN
Low Speed Fault Tolerant CAN
J1850 VPW (Class 2)
J1850 PW M (Ford SCP)
ISO 9141/Keyword 2K/UART/LIN
J1708
CGI
neoVI Device Virtual Network
