5 Signal Ground
6 Discretionary* (GMLAN HS CAN H)
7 K Line of ISO 9141-2
8 Discretionary*
9 Discretionary* (GM ALDL)
10 - line of SAE J1850
11 Discretionary* (GMLAN MS CAN L)
12 Discretionary*
13 Discretionary*
14 Discretionary* (GMLAN HS CAN L)
15 L line of ISO 9141-2
16 Un-switched Vehicle Battery Positive
* Discretionary m eans that the J1979 specification leaves this pin for use by the m anufacturer.
neoVI Documentation - (C) Copyright 2000-2019 Intrepid Control Systems, Inc.
Last Update: Thursday, July 09, 2009
PW R GND
HS CAN H
ISO K
J1850 PW M L
MS CAN L
HS CAN L
ISO L
VBATT
neoVI Blue Connection
13
14
8
5
17
15
7
25
