Intrepid Hardware Help
Medium Speed CAN
Medium Speed CA N - neoVI
Main
A pplies to
neoVI Blue, neoVI Red, and neoVI
FIRE
The neoVI m edium speed CAN channel is an ISO 11898 Dual W ire CAN Physical Layer (82C251) CAN channel. Lik e
all CAN
Channels, this channel has program m able
baud rate/bit tim ing
and
CAN device m
ode. This channel is
functionality equivalent to the high speed channel ex cept for that the neoVI circuits for the high speed channel are optim ized.
According to the ISO 11898 specification, the ends of the CAN network cabling should be term inated. This is described in a
separate
topic.
neoVI Documentation - (C) Copyright 2000-2019 Intrepid Control Systems, Inc.
Last Update: Thursday, July 09, 2009
21 / 71
