Hardware Settings

Main
A pplies to
neoVI Red and neoVI FIRE
W hile m ost neoVI settings are software program m able a few are set with hardware. The term ination resistors for low speed fault tolerant CAN set in hardware. Table 1 and Figure 1 ex plain how to m ak e these settings.
Setting
Low Speed Fault Tolerant CAN Term ination
neoVI Documentation - (C) Copyright 2000-2019 Intrepid Control Systems, Inc.
Last Update: Thursday, July 09, 2009
Table 1 - Hardware Settings in the neoVI device
Bubble in Figure 1
A
Figure 1 - The neoVI has three settings inside the box.
Instructions
Insert two 0.25 W resistors end to end in the sock ets. See
Low Speed Fault Tolerant CAN network for details.
Hardware Settings
term inating a
