LIN : Local Interconnect Network - neoVI
Main
A pplies to
neoVI Blue, neoVI Red, neoVI FIRE, and neoVI
neoVI supports com m unication on LIN (Local Interconnect Network ).
O nce detecting a proper Sync Break and Sync field, the neoVI will wait for the Msg Identifier field. The m essage reception will begin with the Msg ID field. The neoVI will receive the entire m essage according to the LIN spec.
After receiving the m essage error free, the neoVI will send the received m essage to the host starting with the Msg ID field.
If there are any errors neoVI will report the errors back to the host. Table 1 below lists the errors check ed for by the neoVI device.
neoVI supports acting as a m onitor, m aster, and slave.
Enabling LIN is done in the Hardware Ex plorer. For neoVI Blue LIN is enabled under the ISO 9141/KWord 2K/UART/LIN options. Set the Mode to "LIN Mode" and the "Rx Transceiver" to LIN. Also m ak e sure the baud rate is
correct for your network (Figure 1).
To Enable LIN on a neoVI FIRE, neoVI Red, and neoVI
Error
ISO _LIN_SYNC_BRK_ERR
ISO _LIN_SYNC_LEN_ERR
ISO _LIN_SYNC_W AV_ERR
ISO _LIN_MSG_ID_PRTY
neoVI Documentation - (C) Copyright 2000-2019 Intrepid Control Systems, Inc.
Last Update: Monday, June 01, 2009
Yellow
Figure 1 -LIN mode is entered via the neoVI Explorer.
Yellow is done in Hardware Ex plorer by Selecting the channel under network Enables and then setting the proper baud rate for that LIN channel (Figure 2)
Figure 2 -LIN mode is enabled via the neoVI 3G Explorer.
Table 1 - Errors detected in LIN mode.
Figure 3 - A LIN Message
Description
The Sync Break did not have all zero's
The Sync Break did not have at least 9 zero's
The Sync Waveform received after a valid Sync Break was not 0x 55
The MSG ID field was not valid based on the MSG ID parity bits

Local Interconnect Network (LIN)
