Specifications

Specifications
Main
A pplies to
neoVI Yellow
Device Specifications
• 2 DSPs and 1 RISC processor for 88 MIPS of processing
• 1 MB m essage buffer* Power Consum ption (typical) : 100m A @ 14.4 VDC
• Sleep Power Consum ption (typical) : 8m A @ 12.0 VDC
• Power Supply: 5.5-32 Volt Power O peration
• Tem perature Range: -40C to +85C
• Vehicle Connectors : 15 Pin m ale D-SUB
• General Purpose IO : 3 MISC IO (0 - 3.3V)
• General Purpose IO rate report interval: 1 Hz to 10 Khz or based on digital change
• Microsoft© Certified USB drivers
• Isolated USB 2.0 Full Speed Device back ward com patible with USB1.1
• Stand-Alone Mode Including Scripting, Receive Messages, Transm it Messages, Ex pressions, IO , and Transport Layers
• RS232 host port with HW handshak ing support for scripting and gatewaying network data
• ICS Tim eSync for Multiple Hardware Synchronization supports all neoVI 3G devices
• J2534 and RP1210 A/B com patible for CAN/ISO 15765, J1708, Keyword, and ISO 9141
• m icroSD card slot support up to 12 Gigabytes of storage. The rem ovable card is form atted using FAT32 for direct usage in a PC.
• Battery back ed real-tim e clock (RTC)
• Warranty: O ne Year Lim ited Warranty
• Firm ware: Field upgradeable design (flash firm ware)
Networks - General
• 64 Bit tim e stam ping to accuracy of 10 m icroseconds on network s and never overflows. 0.5 m icrosecond accuracy tim estam p available if using one network only
• Sim ultaneous operations on all network s
• Transm it m essage double-buffering on all network s allows back to back m essage transm ission
Network Specifications
2x J1939/CA N Channels
• 2 Dedicated ISO 11898 Dual W ire CAN Physical Layer (TJA1040)
• CAN 2.0B Active
• Up to 1 M-Bit Software Selectable Baud Rate (auto baud capable)
• Capable of generating and detecting error fram es
• Logic Analysis of CAN Waveform with 25 nanosecond resolution
• Graphical Bit Tim e / Baud Rate Calculator
• Listen only m ode support* Unterm inated network detection
J1708
• High precision tim e capture of J1708 bus events
• Software selectable param eters including baud rate
• SAE J1708 Physical layer
K and L Line, 1x LIN (Local Interconnect), ISO9141, or Keyword 2000
• UART Based State Machine
• Initialization Waveform s including Fast Init, Five Baud, and Custom
• Program m able Tim ing Param eters including Inter-Byte, TX Inter-Fram e, RX Inter-Fram e and Initialization Waveform s (0.5 m s Resolution) Full support for LIN 1.X, 2.X and J2602
• K and L have software controlled transm it enable lines allowing m any different variants of UART or ISO 9141 com m unications including:Tx on L Rx on K (full duplex );Tx and Rx on K (half duplex );Tx on K and L and Rx on K
• Sock et selectable pull up resistor on both K and L lines
• Capable of Generating LIN Waveform s (Including Errors) Using Dedicated O utput Com pare Hardware
• Software Selectable Baud Rate
• LIN Bus Monitor Mode identifies errors : Sync Break Error State and Length, Sync Wave Error, Message ID parity, TFram eMax /Slave Not Responding, Check sum Error and Transm it Bit Errors.
• LIN Bus Master Mode operates at sam e tim e as LIN Bus Monitor
• LIN Bus Slave sim ulation - with or without an LDF file
• LIN Bus hardware schedule table with support for LIN diagnostics GM Class 2/ SAE J1850 VPW
• VPW Physical Layer capable ofTx and Rx operations in high speed m odes (MC33390)
• Reception of IFR data during rx and tx
• Long Message transm it and reception for ECU flashing
