UA RT Initialization Waveforms - neoVI

Main

A pplies to

neoVI Blue, neoVI Red, neoVI FIRE, and neoVI

Som e UART standards such as Keyword 2000 and ISO 9141 require you to initialize an ECU before attem pting to send m essages to it. Usually this initialization involves signaling on either or both of the K and L line. You can

select the initialization from the Init table section of the ISO 9141/KeyWord 2000/K-Line section of the hardware Ex plorer (figure 1)

You can cause a initialization to occur on the network by click ing the Init colum n in Vehicle Spy or setting the init flag in the status bit-field in the m essage you send via the DLL. The m essage can have no data bytes (for five

baud initialization for ex am ple).

neoVI supports the standard initializations lik e Fast Init and Five Baud. Also, neoVI also offers a custom initialization because there has been a variety of initialization im plem entations.

For custom initializations you can have a 16 step waveform . This is defined in the custom initialization table in hardware ex plorer. Each step can last up to 32.767 seconds and can control both the K and the L line.

Initialization

Fast Init

Five Baud

Custom

Last Update: Saturday, March 21, 2009

Yellow

Figure 1 - Init table option in hardware explorer.

Figure 2 - You can select the init type from the drop down list in neoVI explorer.

Table 1 - Initialization options in Vehicle Spy

Description

A 25 m s low on the K line followed by a 25 m s high followed by the start com m unication m essage

Address 0x 55 transm itted at 5 Baud (0.125 m s / bit)

Waveform is user defined by a six teen entry table
