Axis) Boom Assembly - ODB LCT6000 Owner's Manual

23
19
11
14
16" Diameter Setup,
18" will be different - please verify
*All units are custom made, use numbers as a reference only.
# PART NO.
1 800.707B
2 LCT616.606MA.2
3 LCT616.606MA.1
4 SCL816.810
5 SCL816.814
6 SCL816.812
7 800.704B
8 800.701D
9 SCL816.813
SCL816.813.24
10 Call
11 LCT616.601MA.HD
12 LCT616.603U
ODB COMPANY

11.4 (3 Axis) Boom Assembly

2010 thru present)
(
3
24 24
20
23
13
DESCRIPTION
Boom Mast
Boom Arm, Up/Down
Boom Arm, In/Out
Cylinder, In/Out
Pin
Cylinder, Up/Down
Auburn Gear
Hydraulic Motor
Hose Support Tube,18"
Hose Support Tube, 24"
Chain
Nozzle, 45 degree
Hose Support Band
5
22
21
18
9
17
21
24 24
14
# PART NO.
13 SDH.16.120.UC
14 LCT616.616
15 800.708
16 HYF.1028
17 800.712
18 800.710
19 800.711
20 800.713
21 8X.002E
22 8X.002G
23 8X.002F
24 8X.002D
25 800.609
26 800.709
800-446-9823
4
5
22
21 21
17 17
16
21
2
21
17
26
10
6
12
DESCRIPTION
Intake Hose, 10' Long
Hose Clamp
Bolt, 3/4-16 x 4.5" Long
Fitting, 90 degree swivel
Nut, 3/4"
Bolt, 3/4-16 x 7.5" Long
Bolt, 5/8-11 x 4.5" Long
Nut, 5/8"
Bushing, .75"IDx1"ODx1"
Bushing, 1"IDx.375"ODx1"
Bushing, .625"IDx.875"ODx1"
Bushing, .625"IDx.75"ODx.5"
Bearing
Bolt, 3/4-16 x 5" Long
LCT6000
8
7
18
21 21
15
1
25
119
