Brake Assembly - ODB LCT6000 Owner's Manual

ITEM #
0
1
2
3
4
5
6
7
8
9
10
11
12
• #12 Not Included with complete brake assembly. Item Sold Separately.
ODB COMPANY

9.5 Brake Assembly

LCT60C/600/650/6000
PART NUMBER
K23-180-00
K23-181-00
036-089-10
047-107-05
047-108-05
027.005.00
046.009.00
K71-127-00
043.004.00
046-018-00
K71-125-00
042-143-00
027-009-00
046-080-00
046.007.00
046.016.00
005-067-00
006-193-00
DESCRIPTION
LH Complete Brake Assembly
RH Complete Brake Asembly
Backing Plate Assembly
Actuator Lever Arm Assembly, LH
Actuator Lever Arm Assembly, RH
Wire Clip
Retractor Spring
Shoe and Lining Kit
Adjuster Assembly
Adjusting Screw Spring
Magnet Kit containing:
(1) Magnet (Black Wire)
(1) Magnet Clip
(1) Magnet Spring
Plug
Wire Grommet
Anchor Post Washer
Nut Washer Assembly
800-446-9823
109
LCT6000
