Engine Controller-Operating - ODB LCT6000 Owner's Manual

The engine communicate with panels over the CAN bus, two wires that run between the engine ECU
and the control panel. All sensors are monitored by the engine ECU. The control panel gets all engine
information from the engine ECU. Typically, the engine ECU handles all engine alarms, derates and
shutdowns. Alarm lamps and codes are communicated to the control panel from the engine ECU from
which the panel illuminates the appropriate lamp and displays the corresponding code.
Display
Six full time parameters are displayed:
1) Engine Temperature
2) Engine Speed
3) Oil Pressure
For alarms, the display provides the appropriate lamp, the corresponding code and a descriptive message
for the operator. See alarms for additional information.
Menu Access
A number of product settings are accessed via the menu system. To access the menu system, hold
down the MENU button and simultaneously press the ENTER button.
To exit the menu system, it is the same process. Hold down the MENU button and simultaneously
press the
ENTER button.
Available Menus:
Emissions Parameters (iT4)
Active Fault Codes
Stored Fault Codes
Operation Event Log
Alarm Event Log
Engine Parameters
Engine Identification
Module Information
Controller Setup
Panel settings are made in the controller setup menu. A password is required to change settings. Contact
your OEM, engine dealer, distributor or Controls, Inc. for this information.
ODB COMPANY
Operating Section

3.3 Engine Controller-Operating

4) Battery Voltage
5) Fuel Rate or Fuel Level (requires fuel level sender)
6) Engine Hours
View emissions information & Regen Options (Auto, Inhibit, Request)
View active fault codes
View stored fault codes
View last 32 start and stop events (hour stamped)
View last 32 alarm events (hour stamped)
View other engine ECU parameters (i.e. % load, % torque, boost pressure)
View engine model and serial number
Control panel part number and software version
Configure settings for throttle, inputs, outputs and other available options
