Trailer Bed Group - ODB LCT6000 Owner's Manual

1
ITEM# PART NO.
1 SCL822.619A
consists of:
.SCL822.619.T2 Tire only
.SCL822.619.R
2 LCT622.602.L
3 LCT622.604
4 LCT630.601B
5 LCT630.602B
6 LCT622.601.09
LCT630.630.05
7 LCT622.614TE
6000.12
ODB COMPANY

9.1 Trailer Bed Group

7
14 14
13 13
5
DESCRIPTION
Tire and Rim Assembly
Rim only
Battery Box Latch
Battery Box Door
Fender, RH
Fender, LH
Trailer Bed, 600
Trailer Bed, 6000
Axle Assembly, 600
Axle Assembly, 6000
LCT6000
6
12 12
15
13 13
16
ITEM# PART NO.
8 STD.2414
9 OD-60250R
10 OD-60700
11 OD-94706
12 STD.2201
13 STD.2201G
14 STD.2202
15 600.2437
16 LCT600.010
17 LCT60.615B
800-446-9823
1
3
14
14
13 13
11 11
10 10
9 9
17
DESCRIPTION
Tail Light Assembly
LED Light only
Grommett
Plug Harness
LED Market Light, Yellow
Grommett, marker light
LED Marker Light, Red
License Plate Mount Brkt
License Plate Bracket
Licesne Plate Light
LCT6000
2
4
12 12
13 13
8
104
