figure 3b
PTO shown disengaged
figure 3c
safety assist cylinder
figure 3d
PTO shown fully engaged
PTO shown fully engaged
ODB COMPANY
Operating Section

3.7 Engaging the PTO

Thoroughly read and understand the safety and pre-operat-
ing sections of this manual before staring the engine.
Make sure the intake hose is properly attached and make
sure the front of the hose is clear of any objects which could
be inadvertently vacuumed during the PTO engagement
process.
Review the Engine Operating Manual supplied with your leaf
vacuum for specific start-up, maintenance and operating in-
structions. It is especially important to review break-in service
procedures for brand new units.
Engaging the PTO (refer to figures 3b, 3c and 3d):
1. Perform all the pre-starting, pre-operating checks outlined
in the EOM and in this manual.
2. Start the engine as previously discussed in this manual and
in the EOM.
3. Once the engine has been allowed to thoroughly warm up
(engine temperature gauge should read at least 180 de-
grees) pull the throttle control until the engine reaches 1000
rpm.
4. Grasp the PTO handle (fig. 3b) and slowly raise the handle.
NOTE: Some units have a PTO assist cylinder which en-
gages the PTO at a specific speed in order to properly en-
gage the PTO. Because of this the PTO handle only needs
to be raised slightly, then the assist cylinder will take over
and engage the PTO automatically. (fig. 3c)
