11.5 Hinged Boom Frame Assembly - Gear Drive

3
2
ITEM #
1
2
3
4
5
6
7
8
ODB COMPANY
2or 3 Axis units July 2005 and after
5
4
PART NUMBER
800.600C
SCL816.501
800.707A
800.704B
800.801D
800.609
SCL816.503L
SCL816.503R
7
DESCRIPTION
Boom Frame
Bearing
Boom Mast, Knuckle
Auburn Gear (see breakdown next page)
Hydraulic Motor
Frame Support
Boom Stop, LH
Boom Stop, RH
800-446-9823
6
8
1
120
LCT6000
