Boom Group - ODB LCT6000 Owner's Manual

20
14
10
7 7
ITEM # PART NO.
1 LCT616.606A
2 SCL816.606A
3 MP-CS.150.12
4 LCT616.801
5 STD.2320.A
6 STD.2321C
7 STD.2322
8
9 LCT616.615D
10 STD.2320E
11 ZENC.625
ODB COMPANY

10.1 Boom Group

19
18
17
21
6
8
9 9
DESCRIPTION
Boom Arm
Boom Mast
Boom Cylinder
Boom Mast Bearings
Up/Dwn Switch Assmbly
(Items #6 - 9)
Push Buttons w/ Harness
SS Button Hold Down
Push Button Box
Hold Down Bracket
Cover Plate
Nut
May 2012 - present
4
15
15
13
16
4
13
5
ITEM #
12 LCT616.607
13 5CZ.625.4.0
14 600.2322B
15 RMB531
16 9405.4.4
17 LCT617.608
18 M3219.PC
19 200022
20 MP-M3219.S
21 9205.4.4
800-446-9823
1
11
2
3
PART NO. DESCRIPTION
Hose Support Hanger
Bolt
Boom Harness
Bushing
90 Degree Fiting
Hydraulic Hose
Boom Pump Cover
Pump Spacer
Boom Pump
Straight Fitting
11
12
112
LCT6000
